Compact Electro Hydraulic Actuator
| Place of Origin | China |
| Brand Name | jiabo |
| Certification | CCS 、BV |
Product Details
Highlight:
electro hydraulic actuator
,Remote Control Valve System
,compact electro hydraulic actuator
Payment & Shipping Terms
Minimum Order Quantity
100
Packaging Details
standard package
Delivery Time
5-8 work days
Payment Terms
L/C,T/T
Supply Ability
100pices/per
Product Description
The Electro-Hydraulic Actuator (EHA) is an integrated, self-contained drive device that combines electric control and hydraulic power. Different from conventional separate hydraulic system actuators, this all-in-one unit integrates a motor, hydraulic pump, control valve block, oil tank, and intelligent control module into a compact structure. It converts electrical signals into stable and powerful hydraulic driving force to realize precise opening, closing, and modulating control of various valves.
Specially optimized for marine, offshore, petrochemical, and industrial harsh working conditions, the EHA features high output torque, fast response, stable operation, and zero external hydraulic pipeline layout. It effectively solves the problems of complex installation, oil leakage, and unstable pressure of traditional hydraulic actuators. With excellent shock resistance, vibration resistance, and salt spray corrosion resistance, it is the preferred intelligent drive solution for ship fluid control, offshore engineering equipment, and industrial pipeline valve systems.
Technical Item | Specification Parameter |
|---|---|
Actuator Type | Double-acting / Single-acting (Spring Fail-safe Reset) |
Rated Working Pressure | 10–35 MPa (100–350 bar, customizable) |
Output Torque Range | 500–35000 N·m |
Rotation Angle | 90° (±3° adjustable), customizable linear stroke |
Control Mode | On-off control / 4–20mA proportional modulating control / Remote hydraulic control |
Power Supply | AC220V/380V, DC24V/48V (customizable) |
Response Time | 0.8–5s (adjustable according to load) |
Positioning Accuracy | ≤±1% |
Protection Grade | IP65 / IP68 (optional) |
Explosion-proof Grade | Ex d II BT4 / Ex ia II CT6 (optional) |
Working Temperature | -45℃ ~ +120℃ (conventional: -20℃ ~ +80℃) |
Hydraulic Oil Medium | ISO VG32/VG46 anti-wear hydraulic oil, flame-retardant hydraulic fluid optional |
Mounting Standard | ISO 5211 international standard |
Body Material | Ductile Iron / 304/316 Stainless Steel |
Certification | CCS, DNV, ABS, BV marine certification & CE certification |
