Marine Overflow Monitoring and Alarm System
| Place of Origin | China |
| Brand Name | JIABO |
| Certification | CCS 、BV |
Product Details
Highlight:
Marine Overflow Monitoring and Alarm System
,Marine Overflow Alarm System
,Marine Overflow Monitoring System
Payment & Shipping Terms
Minimum Order Quantity
100
Packaging Details
standard package
Delivery Time
5-8 Work days
Payment Terms
L/C,T/T
Supply Ability
100pices/per
Product Description
The Marine Overflow Monitoring and Alarm System is a professional marine-grade safety monitoring device specially developed for liquid overflow prevention and level safety monitoring of ship cargo tanks, ballast tanks, fuel tanks and chemical storage tanks. Designed in strict accordance with marine industry safety specifications and IMO international maritime standards, the system integrates high-precision level detection, signal intelligent analysis, real-time data display, sound-light alarm reminder and interlock protection control functions.
Adopting dedicated marine anti-corrosion, shockproof and moisture-proof design, the system can adapt to harsh marine working environments such as hull vibration, wave impact, high humidity and salt fog erosion. It works with matched marine level sensors to monitor the liquid level change of ship storage tanks in real time. Once the liquid level reaches the preset overflow limit, the system will immediately trigger an alarm signal and support linkage control of liquid inlet valves and conveying pumps to effectively prevent liquid overflow accidents, avoid marine environmental pollution and ship safety hazards caused by overflow, and ensure the safety and standardization of ship loading, unloading and navigation operations.
|
Technical Item
|
Technical Specification
|
|---|---|
|
Product Name
|
Marine Overflow Monitoring and Alarm System
|
|
Matching Sensor Type
|
Marine float level sensor, ultrasonic level sensor, pressure level transmitter
|
|
Input Signal
|
4~20mA DC, 0~10V DC, switch signal, RS485 Modbus signal
|
|
Measurement Accuracy
|
±0.2%FS
|
|
Monitoring Channels
|
1/2/4/8 channels (Customizable)
|
|
Alarm Mode
|
Pre-alarm / Overflow limit alarm (Sound + Light Alarm)
|
|
Alarm Sound Level
|
≥85dB
|
|
Output Signal
|
Relay contact output (5A/250VAC), 4~20mA analog output, RS485 communication output
|
|
Working Power Supply
|
AC220V 50Hz / DC24V (Marine standard dual power supply optional)
|
|
Working Temperature
|
-20℃ ~ +60℃
|
|
Working Humidity
|
≤95%RH (No condensation)
|
|
Protection Grade
|
IP54 / IP65 (Optional)
|
|
Anti-vibration Grade
|
Meet marine standard vibration resistance requirements
|
|
Salt Spray Resistance
|
Suitable for long-term marine salt fog environment
|
|
Display Mode
|
LED/LCD digital display (Liquid level value, percentage, alarm status)
|
|
Data Storage Function
|
Power-off data memory, automatic alarm record storage
|
|
Executive Standard
|
IMO MARPOL Convention, Marine Electrical Equipment Safety Standard
|
|
Warranty Period
|
18 months
|
